Aquasust yog MBBR Media cov chaw tsim khoom thiab cov txheej txheem tshuaj lom neeg, kev ntseeg siab los ntawm ntau tus neeg siv khoom thoob ntiaj teb. Peb cov xov xwm MBBR ua haujlwm nrog kev ua haujlwm siab tshaj plaws ntawm cov kab mob microbial thiab txhim kho kev kho dej khib nyiab, tshwj xeeb hauv cov kab hauv qab no.
MBBR Media
Dab tsi Ua Peb MBBR Media Tshwj Xeeb?
Aquasust MBBR media (Moving Bed Biofilm Reactor) yog tsim los rau ntau yam kev siv dej khib nyiab. Cov hollow -cov khoom siv yas no ntab hauv dej, txhawb kev loj hlob ntawm biofilm ntawm lawv qhov chaw los pab rhuav tshem cov pa phem. Lawv kuj muaj xws li:
- Khoom kim heev:Ua los ntawm FDA-qib 100% nkauj xwb HDPE, ua tau ntev thiab rov ua dua tshiab.
- Kev kho mob siab:Muab thaj tsam ntawm 650-3500 m² / m³, muab qhov chaw txaus rau kev sib txuas ntawm microbial.
- Lightweight Design:Nrog rau qhov ntom ntom ntawm dej (0.94-0.97 g / cm³), lawv nyob twj ywm raug tshem tawm thiab fluidized nrog huab cua thiab dej ntws.
- Ntev -Lusing Durability:Tsim los ntawm patented UV- cov mis tsis muaj zog, tiv taus embrittlement thiab tawg, nrog lub neej ntev tshaj 20 xyoo.
- Qhov chaw -Txuag:Yuav tsum tau hneev taw tsawg dua piv nrog cov pa activated sludge systems, haum rau tej yaam num uas txwv qhov chaw.
- Wide Compatibility:Haum rau hauv nroog, kev lag luam, thiab cov dej khib nyiab aquaculture, nrog rau cov txheej txheem xws li MBR thiab activated sludge systems.
Tshawb nrhiav peb cov neeg nqa khoom Biofilm
Tshawb nrhiav peb cov khoom lag luam qib siab ntawm MBBR xov xwm, nrog rau yuav ua li cas lawv txhim kho kev kho dej khib nyiab.
-
AquaSust's MBBR Media
Hoobkas -
Cov duab ntawm AquaSust's
MBBR Media -
AquaSust's MBBR Flowing
hauv dej
Aquasust MBBR Media Specification
|
Mbbr Media (Hom) |
Txoj kab uas hla * Qhov siab (mm) |
Cheeb tsam (m / m³) |
InsideVoid Loj (mm) |
Tus naj npawb ntawm units ib m³ |
|
AS -MBBR.04 |
11*7 |
>900 |
5-6 |
940K |
|
AS -MBBR.05 |
>1000 |
980K |
||
|
AS -MBBR.06 |
16*10 |
>800 |
7-8 |
260K |
|
AS -MBBR19 |
25*12 |
>650 |
118K |
|
|
AS -MBBR 37 |
>800 |
5-6 |
||
|
AS -MBBR 38 |
25*10 |
|||
|
AS -MBBR 64 |
25*4 |
>1200 |
Cim |
21K |
|
AS -MBBR78 |
>1600 |
210K | ||
|
AS -MBBR 92 |
25*4 |
>1700 |
190K |
AS -MBBR 04
AS -MBBR 05
AS-MBBR 06
AS -MBBR 19
AS -MBBR 37
AS -MBBR 38
AS -MBBR 64
AS -MBBR 78
AS -MBBR 92
Peb Featured Biofilter Media
- AS -MBBR05
- AS -MBBR19
- AS -MBBR37
- AS -MBBR78
- AS -MBBR92
-
AS -MBBR05● Loj qhov chaw:AS-MBBR05 nta thaj tsam ntawm 1000 ㎡/m³. Qhov no muab qhov chaw txaus rau kev sib txuas ntawm microbial, ua kom cov colonization ntawm ntau cov kab mob. Nws tuaj yeem siv tau zoo hauv kev kho dej phwj tuaj, pab txhawb kev kho kom zoo dua qub.
● Tsim nyog rau cov txheej txheem lom neeg muaj feem xyuam:Nrog rau qhov tsis muaj qhov loj me ntawm 5 - 6 hli thiab txoj kab uas hla ntawm 117 hli, thiab 980K units ib m³, nws tsim ib qho chaw zoo micro -. Nws yog yoog rau cov txheej txheem kev kho mob lom neeg xws li nitrification, qhov twg cov kab mob sib txuas tuaj yeem koom nrog cov tshuaj biochemical cuam tshuam.
● Kev ua tau zoo ntawm daim ntawv thov:Kev sib xyaw ua ke ntawm nws cov qauv tsis sib xws (qhov loj me, qhov tsis muaj, qhov ntau ntawm ib chav tsev ntim) tso cai rau nws los ua lub luag haujlwm hauv kev kho dej phwj tuaj. Txawm hais tias nyob rau hauv me me - cov dej phwj tuaj kho los yog ua ib feem ntawm cov txheej txheem dej khib nyiab loj dua, nws tuaj yeem pab txhawb kev loj hlob thiab cov metabolism hauv cov zej zog microbial, pab ntxuav cov dej phwj los ntawm kev ua microbial. -
AS -MBBR19● Haum rau kev kho dej phwj tuaj:AS-MBBR19 muab tub lim yog cov khoom siv zoo tshaj plaws thiab siv dav hauv MBBR txheej txheem, haum rau cov dej phwj hauv nroog thiab kev kho dej khib nyiab.
● Moderate surface area (>650 m²/m³):Nws muab qhov chaw txuas ntxiv lom neeg zoo dua, uas yog qhov tsim nyog rau kev loj hlob ntawm microbial thiab kev kho dej phwj tuaj.
● Muaj zog fluidity:AS-MBBR19 muab tub lim muaj qhov pore loj dua thiab hnyav dua. Yog li nws yog ib qho yooj yim los khiav hauv lub reactor kom ua tau zoo dua ntawm biofilm rov ua dua tshiab.
Kev cuam tshuam zoo rau kev thauj khoom: Nws tuaj yeem tiv taus qhov hloov pauv ntawm cov dej tsis zoo, tshwj xeeb tshaj yog haum rau lub sijhawm muaj kev hloov pauv loj hauv cov dej phwj tuaj. -
AS -MBBR37● Moderate surface area (>800 m²/m³):Nws muaj thaj tsam loj dua kev sib txuas. Qhov no ua rau nws tsim nyog rau siab - thauj cov dej phwj tuaj kho, txhawm rau txhim kho kev tshem tawm ntawm ammonia nitrogen thiab cov organic teeb meem.
● Haum rau kev sib sib zog nqus denitrification:Vim nws qhov chaw loj, AS-MBBR37 muab tub lim yog qhov tsim nyog rau cov txheej txheem nitrification thiab cov uas yuav tsum tau ua kom zoo denitrification (xws li BAF, AAO txheej txheem).
● Ntau txoj kev tsim qauv:Lub geometric tsim ntawm AS-MBBR37 muab tub lim yog qhov nyuaj dua li ntawm AS-MBBR04 muab tub lim. Nws txhim kho microbial txuas thiab suits zoo dua rau qhov kub thiab txias los yog qis load ib puag ncig.
● Tsim nyog rau siab -Load industrial wastewater:Vim nws muaj zog biofilm nqa peev xwm, AS-MBBR37 muab tub lim ua tau zoo nyob rau hauv kev kho mob siab -concentration organic wastewater xws li: ua zaub mov, aquaculture, thiab tshuaj. -
AS -MBBR78● Cov cheeb tsam loj dua:AS-MBBR78 muab tub lim muaj qhov sib txuas ntawm cov kab mob lom neeg loj dua, yog li nws tuaj yeem txhawb nqa cov kab mob ntau dua. Nws yog siv feem ntau hauv siab - cov dej phwj tuaj, nrog kev kho kom zoo dua qub.
● Haum rau kev sib sib zog nqus denitrification:Vim nws qhov chaw loj, AS-MBBR78 yog qhov tshwj xeeb tshaj yog haum rau cov txheej txheem xws li nitrification thiab denitrification. Nws yog tshwj xeeb tshaj yog haum rau cov uas yuav tsum tau sib sib zog nqus denitrification, xws li BAF thiab AAO.
● Structure complexity:Lub geometric tsim ntawm AS-MBBR78 muab tub lim yog qhov nyuaj dua, nrog kev txhim kho kev muaj peev xwm ntawm cov kab mob. Nws yog tshwj xeeb tshaj yog haum rau kev kho dej phwj nrog hnyav loads, optimize qhov kev loj hlob thiab kev loj hlob ntawm microbial pejxeem.
● Tsim nyog rau kev kho dej khib nyiab:AS-MBBR78 muab tub lim muaj qhov muaj zog load- cov kabmob muaj peev xwm, uas yog tshwj xeeb tshaj yog haum rau siab -kev sib xyaw ua haujlwm cov dej khib nyiab. Nws tuaj yeem txhim kho kev kho mob zoo, thiab siv dav hauv kev lag luam xws li petrochemicals, steel, thiab tshuaj. -
AS -MBBR92● Txhim kho huab hwm coj kev hloov pauv:Ntau qhov tuaj yeem ua rau muaj kev kub ntxhov ntawm cov dej ntws hauv lub reactor, txhawb kev sib cuag ntawm cov dej phwj tuaj thiab biofilm, thiab pab txhawb kev hloov ntawm cov organic teeb meem, ammonia nitrogen thiab lwm yam substrates los ntawm lub cev dej mus rau saum npoo ntawm biofilm. Nyob rau tib lub sijhawm, nws yog qhov tsim nyog rau kev tso tawm cov pa roj xws li carbon dioxide thiab nitrogen uas tsim los ntawm microbial metabolism, txhim kho kev kho kom zoo ntawm lub reactor.
● Txhawb kev loj hlob microbial thiab txuas:Cov qauv pore nplua nuj muab cov chaw txuas ntxiv rau cov kab mob, ua rau thaj chaw tshwj xeeb ntawm biofilm, thiab tsim nyog rau kev loj hlob thiab kev tsim tawm ntawm ntau yam kab mob xws li kab mob aerobic, kab mob anaerobic, thiab cov kab mob facultative, tsim kom muaj kev sib txawv thiab ntau haiv neeg cov kab mob microbial, thiab txhim kho kev tshem tawm cov pa phem sib txawv.
● Txhim khu kev ruaj ntseg:Lub 92 qhov sib npaug sib npaug, ua rau cov dej ntws sib npaug sib npaug hauv lub reactor, tsis txhob muaj dej luv luv lossis qhov chaw tuag, txo qhov cuam tshuam ntawm cov dej tsis zoo thiab hydraulic shock, thiab txhim kho kev ruaj ntseg thiab kev ntseeg siab ntawm MBBR system ua haujlwm.
● Optimization ntawm hydraulic tej yam kev mob:Qhov tsim nyog tus naj npawb ntawm qhov thiab qhov pore loj tsim tuaj yeem tswj hwm lub sijhawm hydraulic tuav thiab cov yam ntxwv hauv lub reactor, optimize lub xeev cov dej phwj tuaj, txhim kho cov kev kho mob, txo cov sludge poob, thiab xyuas kom meej stability ntawm effluent dej zoo.
Lwm hom MBBR Media
Bio Balls
Eckel Pob
Pob HPU
| Loj | 16 | 26 | 36 | 46 | 56 | 76 |
| Khoom siv | PP + PU | |||||
| Pob | 1000/bag | 4000 / hnab | 1500 / hnab | 800 / hnab | 400/bag | 180/pob |
| Number/cbm | 244000/m³ | 57000/m³ | 21400/m³ | 9800/m³ | 5900/m³ | 2280/m³ |
| Lub npe | Specification | Txoj kab uas hla * Qhov siab |
Thaj tsam tshwj xeeb m² / m³ | Tus nqi qis% | stacking Number/m³ |
Qhov hnyav / g |
| Eckel Pob | φ40 | 40*40 | 300 | 87 | 18500 | 4.2 |
| Yam khoom | Pob Specs | MBBR Spec |
| Pob HPU 80 | Pob HPU 80 Txoj kab uas hla: 80mm Khoom siv: PP |
5pcs MBBR (20 * 20 * 20mm) Khoom siv: Dawb Hydrophilic Polyurethane |
| Pob HPU 80 | Pob HPU 80 Txoj kab uas hla: 80mm Khoom siv: PP |
5pcs MBBR (20 * 20 * 20mm) Khoom siv: Dawb Hydrophilic Polyurethane |
| Pob HPU 100 | Pob HPU 100 Txoj kab uas hla: 100mm Khoom siv: PP |
10pcs MBBR (20 * 20 * 20mm) Khoom siv: Dawb Hydrophilic Polyurethane |
| Pob HPU 100 | Pob HPU 80 Txoj kab uas hla: 100mm Khoom siv: PP |
6pcs MBBR (30 * 30 * 30mm) Khoom siv: Dub Polyurethane |
Tshawb nrhiav Kev Siv AquaSust MBBR Bio Media
- Recirculating aquaculture systems (RAS) thiab ntses los yog cw pas dej
- Municipal thiab industrial dej phwj kho nroj tsuag
- Khoom noj khoom haus, dej haus, mis nyuj, pulp & ntawv, thiab tshuaj lom neeg kev lag luam effluent
- Cov txheej txheem kho mob siab heev xws li MBR thiab A²O systems
Nrog rau cov kev daws teeb meem thiab cov ntawv pov thawj zoo, Aquasust ua kom txhua qhov MBBR media system ua tau raws li cov kev xav tau tshwj xeeb ntawm koj qhov project kho dej khib nyiab.
Sib tham txog Kev Kho Dej Kho Dej
Xav tau kev pab xaiv txoj cai MBBR Media?
Hu rau peb cov kws tshaj lij rau kev coj ua kom haum thiab nrhiav kev daws teeb meem zoo tshaj plaws rau koj qhov project kho dej khib nyiab.
Vim li cas Lag luam wholesale MBBR Media Los ntawm AquaSust?
Raws li MBBR cov chaw tsim khoom lag luam uas ntseeg siab, AquaSust tau muab siab -cov khoom siv biofilm zoo rau cov neeg yuav khoom thoob ntiaj teb rau ntau dua 10 xyoo. Nrog rau qhov zoo li hauv qab no, peb tuaj yeem xa cov kev cai kho dej rau koj cov txheej txheem tshwj xeeb.
01
Xeev- ntawm--Art Manufacturing Facilities
Nrog ntau tshaj 20 xyoo ntawm kev paub hauv kev kho dej, AquaSust tau txais kev txhawb nqa los ntawm nwstus kheej lub Hoobkasthiab muaj zog technical resources. Peb ua haujlwm nrog ntau lub tsev kawm qib siab hauv Suav teb los muab kev txhawb nqa rau MBBR kev sib tham xov xwm, tsim, tsim khoom, thiab xaiv daim ntawv thov.
02
Muaj peev xwm R & D muaj zog
Peb tau tsim muaj kev mob siab rauPab neeg R & Dthiabxeem center,tsis tu ncua innovating cov khoom mis mis los muab siab -kev ua tau zoo biofilm nqa.
03
Cov khoom ruaj khov
Peb zoo sib txuas ua ke txhua qhov txuas ntawm cov kab ntau lawm, thiab teb rau koj cov kev xav tau sai, xyuas kom cov khoom xa tuaj sai sai nrog cov khoom tsim nyog txaus. Peb ib txwm muab kev txhawb zog rau koj txoj kev lag luam nce qib.
04
Comprehensive Expert Support
Ntawm Aquasust, peb muab kev txhawb nqa derictly los xyuas kom meej tias koj lub tshuab aeration ua haujlwm ntawm qhov ua tau zoo. Peb cov kev pabcuam suav nrog:MBBR Tank suav suavs, Dosing Guidance, Maintenance Assistance,lwm.
Related Blogs
FAQ
-
1. MBBR thev naus laus zis txawv li cas los ntawm cov qauv kev kho mob lom neeg?
Tsis zoo li cov txheej txheem ib txwm siv los ntawm kev tshem tawm cov sludge nkaus xwb, MBBR thev naus laus zis ua ke ob qho tib si ncua thiab txuas nrog kev loj hlob. Qhov no hybrid mus kom ze txhim kho nitrification thiab COD tshem tawm thaum txo qhov kev pheej hmoo ntawm sludge bulking. Nws kuj tseem ua kom yooj yim rau kev khiav lag luam, vim tsis muaj sludge recycling yuav tsum tau.
-
2. Cov txheej txheem kho MBBR txhawb nqa nitrogen thiab phosphorus tshem tawm li cas?
MBBR cov txheej txheem kho tau zoo heev rau kev tshem tawm cov nitrogen lom los ntawm nitrification thiab denitrification, tshwj xeeb tshaj yog MBBR media rau aquaculture . Thaum sib xyaw ua ke nrog kev tshem tawm cov phosphorus lom lossis tshuaj lom neeg, MBBR thev naus laus zis tuaj yeem pab cov nroj tsuag tsis tu ncua raws li cov kev txwv tsis pub noj zaub mov nruj.
-
3. Dab tsi ntawm cov khoom siv biofilm siv hauv cov dej khib nyiab?
Muaj ntau yam khoom siv biofilm siv rau kev kho dej phwj tuaj, suav nrog cylindrical, disc -zoo li tus, thiab Kaldnes K1-k5 mbbr media. Cov HDPE cov xov xwm no muaj qhov sib piv ntawm thaj chaw siab, UV- cov ntaub ntawv tiv taus, thiab clog- tiv thaiv geometries, uas tuaj yeem ua tiav kev kho mob mus ntev thiab nyob ruaj khov.
-
4. Dab tsi yog daim ntawv thov tseem ceeb ntawm cov khoom siv biofilm no?
Cov mbbr lim xov xwm no tau siv dav hauv kev kho dej hauv nroog, khoom noj khoom haus & dej haus khib nyiab, textile dyeing, aquaculture, thiab roj refinery effluents. Lawv tshwj xeeb tshaj yog pab tau rau retrofitting cov dej khib nyiab uas twb muaj lawm uas yuav tsum tau muaj peev xwm ntau dua yam tsis muaj kev nthuav dav siv av.
-
5. Yuav ua li cas xaiv txoj cai mbbr cov xov xwm?Xaiv qhov tsim nyog MBBR media nyob ntawm mbbr cov khoom siv, mbbr xov xwm specification, dej ntws tus nqi, organic load, thiab xav tau kev kho mob efficiency. Cov khoom muaj xws li xov xwm ceev, ntu ntu ntu, thiab thaj chaw saum npoo av, uas cuam tshuam rau kev loj hlob ntawm biofilm thiab kev ua haujlwm tag nrho.
-
6. Dab tsi yuav tsum nco ntsoov thaum tsim STP siv MBBR media?
Tsim cov nroj tsuag nrog MBBR kev kho dej khib nyiab yuav tsum tau ua tib zoo xam cov khoom thauj khoom sib piv, thaj chaw tshwj xeeb (m² / m³), kev hloov pauv oxygen, thiab lub sijhawm tuav hydraulic (HRT). Tus tsim yuav tsum sib npaug ntawm kev tawm suab, aeration, thiab sib tov kom ruaj khov biofilm kev loj hlob thiab tiv thaiv clogging.
-
7. Koj puas muab kev pabcuam tsim kho rau MBBR tshuab?Yog lawm. Ntawm AquaSust, peb muab cov txheej txheem MBBR tsim, suav nrog cov txheej txheem simulation, kev xaiv xov xwm, kev teeb tsa lub tank, thiab cov txheej txheem aeration. Peb tus qauv tsim ua kom ntseeg tau tias txhua qhov haujlwm ua tau raws li cov qauv tso tawm hauv zos thaum txhim kho cov nqi khiav lag luam thiab kev siv hluav taws xob.
-
8. Puas muaj kev lees paub rau koj li MBBR bio media?
Yog lawm. Tag nrho MBBR biofilm nqa khoom los ntawm AquaSust suav nrog ib - xyoo lav. Yog tias muaj teeb meem zoo tshwm sim hauv lub sijhawm lav, peb yuav muab kev kho dawb lossis hloov kev pabcuam. Peb xyuas kom meej tias peb cov khoom siv hluav taws xob lom neeg ua haujlwm muaj kev ntseeg siab hauv kev kho dej khib nyiab.
-
![MBBR Media AS-MBBR04 Rau Aquaculture]()
MBBR Media AS-MBBR04 Rau Aq...Technical SpecificationsNtau
Qeb: Biochemical Tank - MBBR Media
Qauv:...
Peb nyob nraum kev MBBR media manufacturers thiab lwm tus neeg nyob hauv Suav teb, tshwj xeeb hauv kev muab cov khoom zoo thiab cov kev pabcuam. Peb sov siab txais tos koj rau cov lag luam wholesale kev cai ua MBBR xov xwm los ntawm peb lub hoobkas.
-
![MBBR Media AS-MBBR04 Rau Aquaculture]()
MBBR Media AS-MBBR04 Rau AquacultureTechnical SpecificationsNtau
Qeb: Biochemical Tank - MBBR Media
Qauv: AS-MBBR04
Loj: Φ11 * 7mm
Khoom siv: 100% Dawb Virgin HDPE
Ceev: 096-0.98g/cm³
Surface Area:...
Peb Loj Hlob Koj Kev Lag Luam hauv 4 Txoj Kev
-
Lag luam wholesale ntawm Hoobkas nqi
Order txheem cov khoom ncaj qha los ntawm peb lub Hoobkas nrog hloov tau MOQ thiab txhim khu kev qha thoob ntiaj teb shipping.
-
OEM & ODM Kev Pabcuam
Custom designs thiab private labeling txaus siab. Co- txhim kho cov khoom tshiab nrog cov neeg siv khoom hauv peb hauv - lub tsev R&D lab.
-
Kev daws qhov project
Peb muab kev kho dej khib nyiab thiab RAS qhov kev daws teeb meem los ntawm kev tsim mus rau kev txhawb nqa.
-
Kev koom tes ntawm cov neeg muag khoom
Koom nrog peb cov neeg muag khoom sib koom ua ke rau cheeb tsam tshwj xeeb, kev pabcuam kev lag luam, thiab luv nqi.
Sib cuag nrog AquaSust
Sau cov lus rau cov lus qhia ntxiv txog peb cov khoom series, thiab thov ib qho kev tsocai lossis cov lus qhia kws tshaj lij.
